OXT | Flush-Mount Module

Roller Shutter Controller | ZigBee | TUYA

▶️ Control of Roller Shutters, Blinds, and Awnings

• Intelligent raising and lowering of roller shutters, blinds, and awnings
• Can be installed in a flush box under a manual switch
• Supports monostable (momentary) and bistable switches – selection in the app

▶️ Flexible Configuration Options

• Two calibration modes: full (following on-screen instructions) or simplified (based on opening time)
• Schedules – automatic opening and closing at set times
• Timers – setting time delays

▶️ Smart Home Integration

• Control via TUYA Smart app (free in App Store and Google Play)
• Create automations based on weather, time, sunrise/sunset, or other TUYA ecosystem events
• Voice control support via Amazon Alexa and Google Home

▶️ Universality and Compatibility

• Works with international voltage standards
• Compact size allows easy fitting into installations

⚠️ Note: A ZigBee 3.0 TUYA gateway (available in our offer) is required for operation.

ℹ️ ZigBee Protocol Basics:

ZigBee operates on the well-propagating frequency of 2.4 GHz

ZigBee connectivity is MESH, which means every ZigBee device with full L+N power acts as a signal repeater for other devices. If a remote sensor cannot connect to the ZigBee gateway, it only needs radio connection with another powered ZigBee device connected to the gateway (up to 3 devices). Devices work in a mesh chain, providing reliability and secure connection.

ZigBee devices react to state changes in 0.2 seconds, while WiFi takes about 5 seconds. This gives ZigBee a significant advantage for smart automation.

WiFi networks start showing problems with 25 devices ❌

You can easily add over 50 devices to a ZigBee gateway ✔️

ZigBee gateways and devices allow longer and more extensive storage of parameters and device history – door opening history, temperature logs, motion detection history stored for months.

ZigBee communication uses very little energy, providing long battery life.

ℹ️ Specifications:

▶️ General Information

• Product Type: ZigBee Roller Shutter Controller
• Protocol: ZigBee 3.0
• Range: up to 100 m
• Certifications: CE, RoHS

▶️ Electrical Parameters

• Rated Voltage: AC 100-240 V 50/60 Hz
• Maximum Current: 3 A
• Communication Frequency: 2.412 GHz – 2.484 GHz

▶️ Operating Environment

• Operating Temperature: -10℃ to +40℃
• Protection Rating: IP20

▶️ Dimensions and Construction

• Dimensions: 39.2 x 39.2 x 18 mm

ℹ️ Calibration:

1. Go to Settings and select Calibration.

2. Follow on-screen instructions (do not close the window until the process finishes).

3. Open and close the roller shutter/curtain using the physical button.

4. A message will appear showing the calibration result.

ℹ️ Package Contents:

• OXT mini ZigBee TUYA roller shutter module
• Mounting clip
• User manual
• Sales document

Product Code: T267
