OXT Mini Module | Dimmer | 1 Circuit | ZigBee | TUYA

▶️ Single-channel flush-mounted WiFi dimmer that transforms your standard switch into a modern, smart device controlled via the Tuya app.

✅ Works with any dimmable light source: including LEDs – only dimmable LEDs supported

✅ Compatible with monostable (bell) or bistable switches: simulates monostable button

✅ Remote control: manage your electrical devices from anywhere using the Tuya app on Android or iOS smartphones

✅ Automations: create smart rules based on weather, time, sunrise/sunset, and other events in the TUYA ecosystem

✅ Voice control: compatible with Google Home and Amazon Alexa

✅ Installation: fits inside a flush box behind the switch (deep or pocket box recommended)

✅ Applications: suitable for any electrical devices

✅ Staircase wiring support: can be used in staircase installations

✅ Schedules: automatic device or lighting activation at specific times, e.g., sunrise/sunset

✅ Timer: switch device on for a set duration

ℹ️ Requires a ZigBee gateway.

▶️ Any model available in our offer.

ℹ️ Basics of the ZigBee protocol:

The ZigBee protocol operates on the well-penetrating frequency of 2.4 GHz, ideal for indoor environments.

ZigBee connectivity uses a MESH network, meaning each ZigBee device powered with full L+N supply acts as a signal repeater for other devices. If a distant sensor can't reach the ZigBee gateway directly, it only needs radio contact with another fully powered ZigBee device that connects to the gateway (up to 3 hops). Devices form a grid chain, ensuring reliability and stable connection.

When devices change state, ZigBee devices connect to the hub in 0.2 seconds, while WiFi devices take about 5 seconds to reconnect after a state change. ZigBee devices have a huge advantage in smart automation rules.

With WiFi, you may start experiencing network issues after 25 devices ❌

With a ZigBee hub, you can easily add more than 50 devices ✔️

The ZigBee gateway and devices allow for much broader and longer data and history storage: door opening logs, temperature history, motion detection records saved for months.

ZigBee communication uses very little energy, which means long battery life for battery-powered devices.

ℹ️ Specifications:

• Rated Voltage: 220-240 V 50 Hz
• Max Current: 0.6 A
• Max Power per LED / Resistive Channel: 150 W

⚠️ Make sure not to exceed the maximum power!

ℹ️ Package includes:

• OXT Mini 1-circuit ZigBee TUYA dimmer module
• Mounting bracket
• User manual
• Packaging
• Sales document

Product code: T265
